Major Parameters:
|
| 1）Power supply voltage：AC 660V/380V ±15％ 50Hz Three phase AC |
| Capacity： Single-rail 3KVA ; Double-rail 6KVA |
| 2）Hoisting Type： hoist person and material (single-rail or double-rail) |
| 3）Brake Distance of the Winder：≤2m |
| 4）Max. Hoisting Distance of the Winder：1200m |
| 5）Max. Hoisting Speed of the Winder：9.9m/s |
| 6）Back-up Protection： |
| Distance detection： ≤300mm |
| Overwinding： 400mm—5000mm (to be determined by the customer) |
| Reserving deceleration point：later than the original deceleration pint of the winder 2m—5m |
| |
| Protection to wrong direction；Protection to depth indicator failure ； |
| 7）Absorber of the railing：to be supplied according to the customer |
| 8）Max. number of the railing：5 (recommend 3 railings) |
| 9）Permissible Power-cut duration：2 months |
